DP-200 Foot Massager

Product name

Foot massage
Model name

DP-200
Norms
5V DC, 1000mA
Adjust the power by the rectifier
WT0502400
Rated voltage
100 - 240V
Rated input power
0.1A
Output waveform
Square wave
Electric pulse repetition frequency
10 - 100Hz
Maximum amplitude of the output voltage
72V
Software version number
MC0188F-REV-V1.0
Rated frequency
50 - 60Hz
Rated output
5V 1000mA
Electric pulse time
115 μS
Performance of load impedance
1 KΩ
Operating Conditions
10-40°C
30%RH ~ 75%RH
860 hPa - 1060hPa
Storage and transmission conditions
0-40°C
≤ 80%RH
860 hPa - 1060hPa

ELECTRICAL MUSCLE STIMULATOR DP-200
